Intraoral cameras

The Acteon C50 HD is a cutting-edge intraoral camera that delivers high-definition imaging for accurate diagnostics and enhanced patient engagement. Renowned for its remarkable clarity and user-friendly design, it seamlessly integrates with dental software, empowering professionals to elevate examination precision and foster better communication with patients. It’s the perfect tool for both routine exams and comprehensive dental evaluations.

Exceptional clinical insight

The C50 intraoral camera harnesses cutting-edge Full HD imaging technology to deliver exceptionally clear and detailed images.

Its outstanding ergonomics are designed to ensure that capturing images is a seamless and effortless experience.

Exceptional clinical adaptability

Achieve a more efficient and high-performing clinical evaluation with our ergonomic 4-in-1 diagnostic aid camera.

With just a single click, seamlessly transition between Daylight vision mode and specialized modes for Daylight+, Perio, or Cario.

C50 full hd intra oral camera built in drivers

Extraordinary operational autonomy

Liberate yourself from limitations with our user-friendly device, fully compatible with your existing setup.

Featuring built-in drivers, the camera requires no installation, offering a seamless experience.

Daylight mode

A comprehensive collection of natural colors enhances the accuracy of tooth shade interpretation, aids in the identification of dental pathologies, and facilitates effective patient monitoring.

c50 daylight plus mode intra oral camera

Daylight+ mode

Striking contrasts that highlight anatomical fissures and intricate details of the dentin’s structure and depth.

Perio mode

The enhancement of dental plaque and gingival inflammation through chromatic amplification.

Cario mode

Fluorescence caries detection using LEDs.

The image boasts a Full HD resolution of 1,920 x 1,080 pixels.

This is the daylight mode enhanced with greater contrasts. The underlying technology adjusts the image contrast settings to a higher default level, ensuring improved visibility of various dental structures.

No, it’s simply a single camera that offers all modes.

The diagnostic aid mode is accessible across all software types, similar to the C50, which is compatible with every kind of software available.

Autofocus allows users to operate the camera without having to manually adjust the focus, as the camera takes care of it automatically. For those who seek greater control over focus and image capture, the option for single focus is available. Autofocus remains the default setting for convenience.

Specification	Details
Sensor	CMOS
Resolution	1920 x 1080px
Sensitivity	2 lux
Frame per second (FPS)	25 – 30
Aspect ratio	16/9
Lighting	6 white LEDs and 2 blue LEDs
Focus adjustment	Automatic focus or Single focus
4 Visions mode	DAYLIGHT mode If option enabled: DAYLIGHT+ mode, PERIO mode and CARIO mode
Depth of field	From portrait to macro
Image capture	Capture button or footswitch (optional)
Angle of view	75°
Cable length	3m
USB output	3.0
Consumption	4.5W max
Handpiece dimensions	L: 200; W: 30; H: 24mm
Handpiece weight	100g
International Protection Marking (IP)	Dust & waterproofness protection IP53
